Semi-automatic Capsule Filling Machine
Semi-automatic Capsule Filling Machine
Semi-automatic orifice-plate capsule filling. Empty capsules are loaded into the upper plate; vacuum-assisted separation orients the capsule body in the lower plate and the cap in the upper plate. Powder/granule is dosed into the body via the dosing disc/scraper; the upper and lower plates are then aligned ,and a pneumatic ram locks the cap onto the body. Filled capsules are ejected.
Features:
1. Touch-screen upgrade over BJ-I-A button-control variant — easier operator interface.
2. Right-sized for small/medium pharma plants and hospital preparation labs.
3. GMP-compliant 304 stainless steel construction.
4. Vacuum pump and one mold included as standard.
Technical Data:
| Model | SED-BJ-III | SED-BJ-III-A | SED-BJ-III-J |
| Capsule Size | 00#-5# | 00#-5# | 00#~4# |
| Capacity (capsules/hr) |
24,000 | 10,000-25,000 | 6,000-30,000 |
| Power Supply | Custom-made according to the customer’s request | ||
| Vacuum Pump | 40m³/hr | 40m³/hr | 40m³/hr |
| Capacity of Air Compressor |
0.03m³/min 0.5-0.8Mpa |
0.03m³/min 0.7Mpa |
0.03m³/min 0.7Mpa |
| Overall Dimension (mm) |
1530*748*1636 | 1140*700*1630 | 1350*780*1635 |
| Weight (kg) | 360 | 280 | 1000 |
Applications:
1. Capsule filling of powders into hard gelatin capsules.
2. Capsule filling of granules into hard gelatin capsules.
3. Hospital preparation, lab capsule production.
4. Small and medium-batch pharmaceutical/nutraceutical capsule production.
Advantages:
Instead of manual filling, this machine can reduce the labor intensity and improve production efficiency.
