High Precision Plugging Injection Adhesive Vacuum Plastic Prefilled Syringe Filling Machine
High Precision Plugging Injection Adhesive Vacuum Plastic Prefilled Syringe Filling Machine
Automatic Plastic Prefilled Syringe Filling and Capping Machine. Filling accuracy ≤±1–2%. Multiple formulation-specific variants: aqueous solution + ointment, glycerol, acid gel. AISI 304 frame; AISI 316L wetted parts; medical silicone rubber. Ceramic plunger pump (acid/alkali-resistant, wear-resistant, high-temp-resistant). PLC + servo controlled.
Features:
1. Suitable for formulations: aqueous solution, paste/ointment, glycerol, acid gel (multiple dedicated variants).
2. Filling accuracy ≤±1–2%
3. Ceramic plunger pump for precision dosing
4. Head-up filling for maximum air elimination
5. PLC + servo motors + HMI
6. Intelligent detection for auto fault alarm
7. Modular design for expansion
8. Optional automatic feeding system.
Technical Data:
| Model | SED-1YGFP-K | SED-2YGFP-K |
| Applicable Materials | liquid and ointment | |
| Applicable Syringe Specifications (ml) |
0.5-80 | 0.5-50 |
| Filling Heads | 1 | 2 |
| Capping Heads | 1 | 2 |
| Filling Accuracy | ≤±1-2% | ≤±1% |
| Production Capacity (pcs/hr) |
1800-2700 | 4200-4500 |
| Power Supply | Custom-made according to the customer’s request | |
| Compressed Air | 0.55-0.75MPa 20L/S | |
| Weight (kg) | 500 | 2000 |
| Overall dimensions (L x W x H mm) |
230*850*1800 | 3650*1300*1800 |
Applications:
1. Prefilled plastic tube syringe filling.
2. Plastic syringe filling.
3. Aqueous solution and paste filling.
4. Glycerol filling.
5. Acid gel filling.
6. Aseptic injectable high-efficiency filling.
7. Aesthetic filler filling.
