Water Bath Autoclave Machine
Water Bath Autoclave Machine
Double Horizontal Sliding Door Water-Shower Sterilizer (Autoclave). Uses high-temperature circulating water as sterilizing medium delivered via spray. Closed circulating system controlled by external cold/hot resources through a heat exchanger. Designed for liquid sterilization in glass vials, ampoules, plastic bottles, and soft IV bags in pharmaceutical industry, and for beverage/food cans in the food industry. Horizontal cylindrical chamber in 316L stainless steel for superior pressure stability and heat uniformity.
Features:
1. Horizontal cylindrical 316L stainless steel chamber for stability under repeated heat/cool cycles.
2. Double horizontal sliding doors, cylinder-driven, with safety interlocks (no pressure with door open; door cannot open under pressure; door locked during cycle).
3. Efficient spiral spray / spray-board system for even heat distribution with no dead corners.
4. Plate heat exchanger with 316 stainless steel plates.
5. Cylinder bottom reservoir reuses pure chamber water — no separate water box.
6. Calcium silicate insulation deck; whole stainless steel wire-drawn external plates.
7. Standard GMP inspection interface (IQ/OQ/PQ programs).
Technical Data:
| Model | 13SM-Q | 29SM-Q |
| Designed Pressure (MPa) |
0.35 | 0.3 |
| Designed Temperature (℃) |
139 | 129 |
| Working Temperature (℃) |
80-126 | 80-126 |
| Sterilizing Time (min) |
70-99 | 0-99 |
| Heat Average | ≤+2℃ | ≤+2℃ |
| Temperature Measurement Accuracy |
≤0.5℃ | ≤0.5℃ |
| Chamber Size (mm) | 2000*φ4350 | 1000*1440*3200 |
Applications:
1. Terminal sterilization of soft IV (LVP) bags.
2. Liquid sterilization in glass vials and ampoules.
3. Plastic-bottle liquid sterilization.
4. Beverage bottle and food can sterilization.
5. Pharmaceutical solution and suspension sterilization.
