High Speed Automatic Rotary Tablet Pressing Machine for pharmaceutical industries
High Speed Automatic Rotary Tablet Pressing Machine for pharmaceutical industries
The variable-frequency main motor drives a reducer via a synchronous toothed belt, and the reducer, in turn, drives a gear train to rotate the turret. Guided by guide rails, the upper and lower punches execute a complete cycle comprising filling, pre-compression, main compression, and tablet ejection. The pre-compression and main compression rollers are independently adjustable, facilitating a two-stage compression process; a hydraulic system provides stable support for the main compression force.
Introduction:
This is a kind of fully automatic rotary tablet pressing machine, which puts all kinds of granular or powdery materials into the holes of the dies, and then presses them into tablets with punches’ heads by a number of punches and dies evenly distributed on the rotary table according to a certain trajectory of circular lifting and lowering movements. This machine uniformly presses tablets with the upper and lower punches at the same time, which means that the air in the particles can be squeezed out of the holes, so it improves the uniformity of the tablets and reduces the cracks of the tablets. It can be used to press various raw materials into tablets for pharmaceutical, chemical, food, electronic, and other industries. Besides, the machine is equipped with a forced feeding mechanism and microcomputer control, which can automatically adjust the pressure, control the weight of tablets, and remove the waste tablets.
This machine can press all kinds of granular raw materials into round tablets, shaped tablets, carton tablets, and tablets with double-sided positioning and engravement and so on.
Features:
1. Dual-pressure compaction ensures optimal tablet quality.
2. Continuously adjustable output over a wide range.
3. Comprehensive safety and overload protection system.
4. Compliant with GMP standards.
5. Compatible with vacuum feeders for automated material loading.
6. Supports batch rejection and automatic tablet weight adjustment.
7. Aesthetically pleasing design with precision craftsmanship.
The working area adopts fully closed transparent windows with less dust pollution and excellent sealing. Components are made of stainless steel or special surface treatment, which can prevent cross-contamination and meet GMP requirements.
Technical Data:
| Model | 370- 32GY-B |
520- 29GY-B |
580- 35GY-B |
580- 37GY-B |
580- 43GY-B |
580- 53GY-B |
580- 57GY-B |
660- 45GY-B |
660- 55GY-B |
660- 75GY-B |
| Number of Punch Die |
32 | 29 | 35 | 37 | 43 | 53 | 57 | 45 | 55 | 75 |
| Max. Main Pressure (KN) |
80 | 100 | 80 | 80 | 100 | 100 | 100 | 100 | 100 | 100 |
| Max. Tablet Diameter (mm) |
16 | 25 | 25 | 23 | 18 | 13 | 11 | 25 | 16 | 13 |
| Production Capacity (pcs/hr) |
30,000- 210,000 |
139,200 | 189,000 | 199,800 | 232,200 | 286,200 | 307,800 | 405,000 | 495,000 | 675,000 |
| Power (kW) | Custom-made according to the customer’s request | |||||||||
| Net Weight (kg) |
1400 | 2380 | 3500 | 3500 | 3500 | 3500 | 3500 | 3980 | 3980 | 3980 |
| Overall Dimension (L*W*H mm) |
1200*950*1850 | 1200*900*180 | 1170*1290*190 | 1170*1290*1900 | 1170*1290*1900 | 1170*1290*1900 | 1170*1290*1900 | 1704*1380*1926 | 1704*1380*1926 | 1704*1380*1926 |
Applications:
1. High-Speed Pharmaceutical Tablet Compression.
2. Health Supplement Tablets.
3. Shaped Tablet Compression.
Advantages:
This series of products is characterized by high manufacturing precision, advanced automation level, fast production speed, stable and reliable use, and low working noise. It can improve the production quality of drugs and the environment, reduce labor intensity and the loss of raw materials, and lower the production costs. It is the ideal equipment for pharmaceutical factories to implement production technology reform and new projects, and meet the requirements of GMP.
