Lab Scale Vacuum Freeze Dryer
Lab Scale Vacuum Freeze Dryer
The vacuum freeze dryer is designed for pharmaceutical applications. It features a pre-freezing function, multi-stage sublimation, and analysis capabilities, with precise control over temperature and pressure. The machine is compact and integrated, suitable for small batch processing.
Features:
1. Compact, Integrated Structure.
2. Precise Temperature and Pressure Control.
3. Suitable for Small-Batch Processing.
4. Cold Trap with Pre-freezing Function.
5. Multi-stage Sublimation.
6. Multi-stage Desorption.
7. Shelf Temperature Uniformity: ±1°C.
8. Pressure Regulation Accuracy: ±1 Pa.
Technical Data:
| Model | 0.18XDG-O |
| Freeze dried area | 0.18㎡ |
| Cold trap temperature | -60 ℃ (optional -80 ℃) |
| Catching water volume (kg/batch) |
6 |
| Standard vacuum degree (Pa) | ≤ 5 (no-load) |
| Ultimate vacuum (Pa) | 0.1 |
| Pumping Speed (L/s) | 4 |
| Material tray | 240mm, 4 layers in total |
| Disc spacing (mm) | 70 |
| Bottled loading capacity of penicillin |
Penicillin bottle Φ 12mm: 1270 pieces
Penicillin bottle Φ 16mm: 716 pieces Penicillin bottle Φ 22mm: 379 pieces |
| Whole machine power (kW) | 1.1 (including vacuum pump) |
| Machine size (mm) | Width 560 * Depth 560 * Height 980 |
| Machine net weight (kg) | 88 |
| Packaging size (mm) | Width 630 * Depth 670 * Height 1500 |
| Total weight with packaging (kg) |
150 |
| Power supply | AC220V 50HZ or 110V/60HZ |
| Application environment | Environmental temperature ≤ 35 °C |
| Operating noise of the entire machine |
≤55dB |
| Warranty Period | Free one-year warranty for the entire machine |
Applications:
1. Pharmaceutical freeze-drying.
