Lab Scale Vacuum Freeze Dryer
Lab Scale Vacuum Freeze Dryer
The lab freeze dryer is a large-scale pharmaceutical vacuum freeze dryer with SUS304 shelves, built-in hydraulic stoppering system, and SIEMENS PLC+DELL PC control. FDA and CE compliant with electronic signature and multi-language interface.
Features:
1. FDA and CE certified — ready for regulated pharmaceutical markets.
2. Recipe management, data logging, electronic signature, remote diagnostics.
3. In-situ hydraulic stoppering for aseptic vial sealing under vacuum.
4. Consistent lyophilization results.
5. PID electric heating — energy-efficient, stable temperature control.
6 Leak-free, low-noise circulation pump.
Technical Data:
| Model | 0.2XDG1-B | 2XDG-B |
| Drying Area (㎡) | 0.2 | 2 |
| Tray Size (mm) | 230*300*9 | 500*500*20 |
| Number of Tray | 3+1 | 8+1 |
| Shelf Temperature (℃) | -40~80 | -55~80 |
| Power | Custom-made according to the customer’s request | |
| Dimension (mm) | 880*766*610 | 1500*1500*2300 |
| Weight (kg) | 100 | 1500 |
Applications:
1. Large-scale pharmaceutical freeze-drying (vials, ampoules, bulk).
2. Biological products and vaccines lyophilization.
3. API and formulation freeze-drying.
4. GMP-compliant production freeze-drying.
